LUXE CANTILEVER
®
LUXE CANTILEVER
®
OVERVIEW
.jpg)
Redefining the limits of outdoor structures, the Luxe Cantilever® range offers three expertly engineered models — Lite, Original, and Max — each built around the same iconic two-post floating design, with varying scale, strength, and customisation to suit your space.
Create your own personalised design, selecting from a range of colour and finish options for a pergola that exudes sophistication, harmoniously integrating into your home and landscape design.
Versatility in Design: Whether you're after a cantilever pergola or a cantilever carport, The Luxe Cantilever® has a sleek, versatile design that can be positioned unobtrusively along a boundary, creating a sense of luxury and openness, a shady sanctuary without poles to walk into or obstruct your view. This makes it the perfect solution for by the pool, carports, smaller spaces or anywhere two posts are better than the traditional four post design.
Expert engineering for stability and ease of installation: The Luxe Cantilever® pergola or carport has been expertly engineered (tested and certified!) to provide the benefits of a floating pergola without compromising on stability, so you can confidently say goodbye to those two pesky pillars in the way. The Luxe Cantilever® pergola is engineered for easy installation, ensuring a seamless and hassle-free process from start to finish.
Enhance your comfort: The Luxe Cantilever® uses Versiclad insulated roofing panels which provide a weather tight cover, outstanding insulation, and a pre-finished, maintenance free ceiling. Versiclad roof panels will keep you cool in summer and warm in winter with a comfortable atmosphere year-round.
Ceiling fans can also be installed, creating a gentle breeze on warm days, or lighting to extend your outdoor enjoyment into the evening. The Luxe Cantilever® is also designed with compatibility in mind, making it easy to integrate security systems or flood lights for added peace of mind.
Please contact us for a free quote and custom design a Luxe Cantilever® to your space.
Not within our service area? We can ship & facilitate the installation of the Luxe Cantilever® anywhere in New South Wales.
Our Services:
Concept Plans
Custom Designs
Approvals (DA/CDC)
Supply & Installation
.png)
Supply Only
.jpg)
SPECIFICATIONS
Sizes (Length x Projection)
Suitable region / Wind rating
Choose for
Material
Frame size
Roof thickness / thermal insulation
Finish
Colours
Customisation options
Installation requirements
4x3m, 3x3m, 3x2m, 2x2m, 2x1m
Height up to 3m
N2 –NSW, ACT, SA, VIC
Projects where simplicity meets performance
Cost-effective cantilever up to 4x3m
Heavy duty aluminium
Posts 190x90
50 to 75mm thickness
Powder coated
Frame: Pearl White, Night Sky (Black), Monument
Ceiling: Pearl White, Luxline, Golden Oak, Micraline
Lighting, fans, security available as standard extras
Fixed directly to 200mm slab or optional piers.
Any custom size up to 6x4m
Height up to 3m
N2 –NSW, ACT, SA, VIC
Size, colour customisation options, extra sleek design with concealed outer fixings
Steel
Posts 150x150
75-100mm thickness
Powder coated
Full suite of Colorbond® matched colours.
Lighting, fans, security standard extras
Can support significant weight such as hammocks, swings, etc
Piers
Up to 6x6m or 7x4m
Height up to 3m
High Wind regions (QLD).
Also used in all regions for Luxe Cantilevers larger than 6x4m
Use in high wind zones or for XL size in all regions
Steel
Posts 150x150 for 7x4m or 200x200 for 6x6m
75-100mm thickness
Powder coated
Full suite of Colorbond® matched colours.
Ceiling: QLD & Northern NSW – check with your authorised installer.
Lighting, fans, security standard extras
Can support significant weight such as hammocks, swings, etc
Piers
The LUXE CANTILEVER® LITE offers the same trusted engineering as the LUXE CANTILEVER® in a light-weight, cost-effective aluminium design.
The light-weight, durable aluminium frame comes in a range of sizes up to 4m x 3m, meaning this it can be bolted directly to a 200mm thick slab without the need for piers if preferred.
Where simplicity meets performance:
for smaller designs up to 4x3m.
Perfect for pool areas, outdoor lounge & BBQ areas.
.jpg)
The original LUXE CANTILEVER® offers the weight and strength of a steel frame, making it scalable to any custom size up to 6m wide x4m projection.
The LUXE CANTILEVER® design requires piers to provide a secure base for the steel frame and features concealed outer fixings for a seamless aesthetic.
For large, premium designs up to 6x4m
Perfect for: carport, over a pool or large outdoor spaces
%20(Large).jpg)
The LUXE CANTILEVER® MAX offers the weight and strength of a heavy- duty steel frame, making it suitable for large cantilevers between 6x4m up to 6x6m or 7x4m and also for cantilevers in high wind weather zones in northern NSW and southern QLD. Please note high wind certification only applies for up to 6mx3.3m max sizing.
For High wind weather zones and large designs ranging between 6x4m up to to 6x6m or 7x4m
Perfect for: Large outdoor spaces, carports & high wind areas
LUXE CANTILEVER SPECIFICATIONS
We offer three cantilever pergola options to suit a variety of projects: the Lite, the Original Luxe Cantilever, and the Max. Select an option from the dropdown below to explore the features and specifications of each model and find the right fit for your space.
Installation requirements
Colours
Frame finish
Roof thickness
Sizes available
Choose for
Suitable region /
Wind rating
Max Size
(Length x Projection)
Material
Fixed directly to 200mm slab or optional piers.
Limited Selection
Powder coated
50 to 75mm thickness
4x3m, 3x3m, 3x2m, 2x2m Let us know if you need a custom size.
Projects where simplicity meets performance – a cost-effective cantilever up to 4x3m
N2 NSW , ACT, SA, VIC
Up to 4x3m Height up to 3m
Heavy duty aluminium
.jpg)
Why the Luxe Cantilever®?
Space Maximization: With only two support poles, the Luxe Cantilever® maximizes your outdoor space, creating an uncluttered and visually spacious environment.
Insulation: Being fully insulated with Versiclad roofing panels means you keep cool in summer and warm in winter.
Customisation: Match the overall style of the space or seamlessly blend into the environment based on the colour choices and finishes available. The roofing, roof colour ceiling finishes and even the frame colour can all be customised when designing your shade solution.
Easy Maintenance: Our design is so strong you can walk on the roof to clean and maintain your Luxe Cantilever®. All materials used have an easy wipe down surface.
Exceptional durability: Our roofing panels are hail proof ensuring your Luxe Cantilever® looks great for years to come.
.jpg)
%20(Large).jpg)
%20(Large).jpg)
DESIGN OPTIONS
CUSTOMISE YOUR LUXE CANTILEVER® PERGOLA
ROOF STYLES
ROOF COLOUR
* Colours not available in 'Spacemaker' roof style
CEILING FINISH
COLOURS
Pearl White
Merino
Cream
FINISHES
Golden Oak
Luxline
Smooth
Micraline
Embossed
FRAME COLOUR
(Steel)
%20(Large).jpg)
.jpg)
.jpg)
Pearl White
Night Sky
.jpg)
Surfmist
.jpg)
Monument
ADD-ONS
.jpg)
%20(Medium).jpg)
.jpg)
ENHANCE YOUR LUXE CANTILEVER®
Downlights, Spotlights & Dimmers:
Illuminate your outdoor haven with precision by incorporating customisable downlights, spotlights, and dimmers into The Cantilever®. Whether you desire a soft ambient glow for relaxed evenings or focused illumination for specific areas, these enhancements allow you to set the perfect mood. With the flexibility of dimmers, you have full control over the brightness, creating an inviting atmosphere tailored to every occasion.
Ceiling Fans:
Maximize comfort under the Luxe Cantilever® with the addition of ceiling fans. Experience a gentle breeze that not only enhances air circulation but also adds a refreshing touch to warm days. Seamlessly integrated into the pergola's design, these fans provide an efficient cooling solution while contributing to the overall aesthetic appeal of your outdoor space.
Coastal Environments:
Engineered to withstand the challenges of coastal environments, the Luxe Cantilever® offers an optional Versiclad Magnaflow technology. This advanced feature ensures durability and resilience against harsh coastal elements. Embrace the beauty of coastal living without compromising on the longevity and performance of your Luxe Cantilever®.
